alazerstream600高速数据流盘系统

alazer stream PCIe 9870 系统  1GHz 采样, 2通道, 1.4GH 连续流盘.

1 GS/s Real Time Sampling per channel
1.4 GB/s throughput across PCIe x8 bus
2 Channels sampled at 8 bit resolution
500 MHz full power bandwidth
+/- 200mV to+/- 4 V Input Range
43 dB Signal to Noise Ratio
NIST Traceable Calibration
FIFO Streaming Mode
Up to 4 GB of on-board Dual-Port Memory
Trigger Input & Trigger Output connectors
Half-Length PCIe x8 Card
AlazarDSO Software allows quick start-up
SDKs for C/C++, C#, VB and LabVIEW
Linux Drivers Available
